products

profile

Mounting
Screw
Side Clearance
height
190mm
Loading
75 lb (34kg)
Size
300,350,400,450,500 mm
feature
Drawer frame mounting design providing the most added-value to cabinets, 6-way adjustment drawer front adjustment, new dampening mechanism, no hassle of grease leaking or drawer boune, extremely light and silent movement.
surface Treatment
  • Clear Zinc
  • Black Zinc
  • GI
Option
Zinc plating on slides, powder coating on drawer frame.
Packaging
  1. Production pack

Quick Installation Guide

NJ-A5803 Concealed Slides (Tall Drawer) for Metal Box,
